2.13 inch E-Ink display HAT for Raspberry Pi, three-color

Note: This 2.13-inch E-Ink display HAT is updated from V2 to V3 from October 2020 onwards. E-Ink (Electronic Ink) display has several benefits compared to other display technologies: High Visibility and Contrast Wide viewing angle and super low power consumption. It can retain the display for very long time after power is removed. This is an E-Ink display HAT for Raspberry Pi, 2.13inch, 212×104 resolution, with an embedded controller, communicating via SPI interface, supports red, black, and white three-color display. Due to the advantages like ultra-low power consumption, wide viewing angle, clear display without electricity, it is an ideal choice for applications such as shelf labels, industrial instruments, and so on. Interface: Dimensions: Features No backlight, keeps displaying last content for a long time even when power down Ultra-low power consumption, basically power is only required for refreshing Compatible with Raspberry Pi Zero/Zero W/Zero WH/Zero 2W/3B/3B /3A /4B Preserved solder pads for SPI interface, for connecting with other controller boards like Arduino, etc Onboard voltage translator, compatible with 3.3V/5V MCUs Comes with development resources and manual (examples for Raspberry Pi/Arduino/STM32) Stack perfectly on Raspberry Pi Zero board and of course a little smaller than Raspberry Pi 3B/3B /4B/5. Specifications: Operating voltage: 3.3V/5V Interface: 3-wire SPI, 4-wire SPI Outline dimension: 65mm × 30.2mm Display size: 23.71mm × 48.55mm Dot pitch: 0.229 × 0.228 Resolution: 212 × 104 Display color: red, black, white Grey level: 2 Full refresh time: 15s Refresh power: 26.4mW(typ.) Standby power: 170° Packing List 1 x 2.13inch E-Ink display HAT(3 colors) board 1 x 8-way JST plug to pigtail jumper wire (female terminated) 2 x 8mm spacer (2.00mm diameter) with screws and nuts Resources Make new larger font for SPI e-Paper Schematic 2.13-inch e-paper datasheet Libraries for Raspberry Pi Wiki page
